Table of Content
Duplex S31803 Double End Stud bolt, ASTM A479 Flange Stud bolt, ASME SA479 Tap End Stud bolt, ASME SA479 Continuous Threaded Stud bolt, Duplex S31803 Continuous Threaded Stud bolt, Saf 2205 Continuous Threaded Stud bolt.
Ranflex Metals are the leading manufacturer of high integrity Duplex S31803 Fasteners (e.g. bolts, set screws, stud-bolts, nuts and washers), meeting clients’ exacting demands for critical applications in hostile environments. Whether for offshore (buoyancy and petrochemical), seawater, pump, valve or nuclear, the demands for an exceptional service and supply is never ending. We believe manufacturing bolting in exotic materials is an art form and it is something we have perfected at Ranflex Metals.
ASME SA479 Flange Stud bolt manufacturer, ASME SA479 Double End Stud bolt distributor, Werkstoff Nr. 1.4462 Welding Stud bolt wholesaler, Duplex S31803 Continuous Threaded Stud bolt exporter, UNS S31803 Double End Stud bolt manufacturer, ASME SA479 Welding Stud bolt stockiest, Saf 2205 Double End Stud bolt supplier.
Our Duplex S31803 Fasteners product range includes Duplex S31803 Steel Bolts, Hexagon head bolt, Hexagon head screw, Round head square neck bolt, Hexagon socket head cap screw in full thread and half thread, Hexagon wood screw, Hexagon socket button head screw, Hexagon socket button flange screw, Hexagon socket counter sunk head cap screw in full thread and half thread, square nuts, square weld nuts, hexagon weld nuts, thick nyloc nuts, hexagon flange nuts, threaded rods, dowel screws, Plain / Flat Washer, Spring Washers, Countersunk Washer,Tooth Lock Washer and many more. We provide products as per DIN, ANSI, JIS standards.
Ranflex Metals produces Duplex S31803 Fasteners in all grades of duplex, to customer specification.ALLOY 31803 is a chromium nickel molybdenum austenitic and ferritic grade. It has improved resistance to stress corossion cracking, piiting, crevice corrossion and high strengths in comparison to other stainless steel grades. It has very good oxidation resiatnce at high temperatures. However, it is prone to embrittlement at 475 Degree celcious if exposed for more than 2 hours. It is widely used in brewing , power generating equipments and wide varierty of marine and oil and gas applicants. If we do not have your Duplex S31803 Fasteners in stock (Inch or Metric) we can have these manufactured to your specification.
UNS S31803 Fully Threaded Stud bolt, Saf 2205 Flange Stud bolt, Saf 2205 Welding Stud bolt, UNS S31803 Tap End Stud bolt, ASTM A479 Welding Stud bolt, ASME SA479 Flange Stud bolt, Werkstoff Nr. 1.4462 Double End Stud bolt, ASME SA479 Fully Threaded Stud bolt.
Specification of S31803 Duplex Stud Bolt :
| Specifications | ASTM A479 / A479, ASME SA479 / SA194 |
| Standard | DIN, ASTM, BS and all International Standards |
| Length | 3 mm to 200 mm |
| Nuts Size | M3 - M56 | 3/6" to 2" | Custom Sizes |
| Stainless Steel Bolt / Screw Size | M3 - M56 | 3/6" to 2" | Custom Sizes |
| Stainless Steel Machine Screws Size | M1.6 - M12 |
| Stainless Steel Washers Size | M3 - M56 | 3/6" to 2" | Custom Sizes |
| Stainless Steel Stud bolts Type | Socket Screw, Hex Set Screw, Cap Screw, Machine Screw, Wing Screw, Spring Washers, Washers, Studs, Marine Anchors, Anchors, Hexagon Nut,U- Bolts, Anchor Bolt, Mushroom Head Square Neck Bolts, J Bolts,Eye Bolt,Structural Bolts, Bolts, Nuts, Sockets, Screws, Allen Cap screw, Nut, Hex Coupling Nut, Hex Nut, Square Nut, Hex Domed Cap Nuts, Hex Head Bolts, Stud Bolts, Socket Hexagon Head Screw, Pan Head Screw, Socket Head Cap Screw, Wing Screw, T-Head Bolts, Foundation Bolts,Screw, Studs |
Equivalent Grades of Duplex S31803 Stud Bolt :
| Duplex | Common Name | Related Specifications | ||
|---|---|---|---|---|
| European DIN | UNS | ASTM/ASME | ||
| Duplex Steel S31803 | SAF 2205® | 1.4462 | S31803 | F51/F60 |
Chemical Composition of S31803 Duplex Stud Bolt :
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S31803 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 21.0 – 23.0 | 2.50 - 3.50 | 4.50 – 6.50 | 0.8 – 0.20 | 63.54 min |
Mechanical Properties of Duplex S31803 Stud Bolt :
| Grade | Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| S31803 | 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80000 , MPa – 550 | Psi – 116000 , MPa – 800 | 15 % |
Physical Properties of Stainless Steel WERKSTOFF NR. 1.4462 :
| Density lbm/in3 |
Electrical Resistivity mW•in |
Thermal Conductivity (BTU/hr•ft•°F) |
Heat Capacity BTU/lbm•°F |
Electrical Resistivity (in x 10-6) |
|
|---|---|---|---|---|---|
| at 68°F | 0.278 | 27.6 | 8.7 | 0.112 | 33.5 |
| at 212°F | 26.1 | 9.2 | 0.119 | 35.4 | |
| at 392°F | 25.4 | 9.8 | 0.127 | 37.4 | |
| at 572°F | 24.9 | 10.4 | 0.134 | 39.4 |
Duplex S31803 Welding Stud bolt stockiest, ASME SA479 Welding Stud bolt wholesaler, Saf 2205 Double End Stud bolt trader, ASTM A479 Double End Stud bolt trader, Werkstoff Nr. 1.4462 Welding Stud bolt exporter, Duplex S31803 Double End Stud bolt stockiest, Saf 2205 Flange Stud bolt dealer.
Modern Equipments
Expert Engineers
Efficient Factories
Well Maintained
Property Class of Stud Bolt S31803 Duplex :
Looking for S31803 Duplex Stud Bolt? Ranflex Metals is a top-class manufacturer of S31803 Duplex screws. We are the most experienced among all the steel fasteners market and progresses with a highly professional team who is wholly engaged in making S31803 Duplex screws, S31803 Duplex bolts, and Fastener at the lowest cost.
For Bolts & Screws: A2-70, A2-80, A4-70, A4-80, F593C, F593D, F593G, F593H
For Nuts: A2-70, A2-80, A4-70, A4-80, F594C, F594D, F594G, F594H, A2-035, A4-040
For SHCS: F837B, F837C, F837E, F837
For Threaded Rods: A2-70, A2-80, A4-70, A4-80, F593C, F593D, F593G, F593H, B8, B8M CL1 & CL2
Dimensions of Duplex S31803 Stud Bolt :
Duplex S31803 Stud Bolts Dimensions Chart :
| Diameter | ||
|---|---|---|
| Plain | ||
| UNC | 8UN | |
| 1/2 | 19568 | - |
| 5/8 | 19569 | - |
| 3/4 | 19570 | |
| 7/8 | 19571 | - |
| 1 | 19572 | - |
| 11/8 | 19573 | 13979 |
| 11/4 | 19574 | 13980 |
| 13/8 | 19656 | 13981 |
| 11/2 | 19657 | 13982 |
| 13/4 | 19658 | 13983 |
| 2 | 19659 | 13984 |
| Available lengths 12 Inch ASME B18.31.3, Also available lengths Dimensions 6 Inch |
||
Duplex S31803 Threaded Rod Dimensions Chart :
| D | P |
D
|
P |
|---|---|---|---|
| M2 | 0.4 | M20 | 1.5/2.5 |
| M2.5 | 0.45 | M22 | 1.5/2.5 |
| M3 | 0.5 | M24 | 2/3 |
| M3.5 | 0.6 | M27 | 2/3 |
| M4 | 0.7 | M30 | 2/3.5 |
| M5 | 0.8 | M33 | 2/3.5 |
| M6 | 1 | M36 | 3/4 |
| M8 | 1/1.25 | M39 | 3/4 |
| M10 | 1/1.25/1.5 | M42 | 3/4.5 |
| M12 | 1.25/1.5/1.75 | M45 | 3/4.5 |
| M14 | 1.5/2 | M48 | 3/5 |
| M16 | 1.5/2 | M52 | 3/5 |
| M18 | 1.5/2.5 |
Size of Duplex S31803 Stud Bolt :
Duplex S31803 Nuts Size Chart :
| Size Of Nut (millimeter) |
Diameter Of (millimeter) |
Height Table (millimeter) |
||
|---|---|---|---|---|
| Hex Nut | Jam Nut | Nylock Nut | ||
| 2 | 4 | 1.6 | 1.2 | - |
| 2.5 | 5 | 2 | 1.6 | - |
| 3 | 5.5 | 2.4 | 1.8 | 4 |
| 4 | 7 | 3.2 | 2.2 | 5 |
| 5 | 8 | 4 | 2.7 | 5 |
| 6 | 10 | 5 | 3.2 | 6 |
| 7 | 11 | 5.5 | 3.5 | - |
| 8 | 13 | 6.5 | 4 | 8 |
| 10 | 17 | 8 | 5 | 10 |
| 12 | 19 | 10 | 6 | 12 |
| 14 | 22 | 11 | 7 | 14 |
| 16 | 24 | 13 | 8 | 16 |
| 18 | 27 | 15 | 9 | 18.5 |
| 20 | 30 | 16 | 10 | 20 |
Duplex S31803 Threaded Rod Size Chart :
|
Size Table Of Threaded Rod
|
per Inch Threads
|
||
|---|---|---|---|
|
Frac. [Number]
|
Decimal
|
UNC
|
UNF
|
|
1/8 [#6]
|
0.1380
|
32
|
40
|
|
5/32 [#8]
|
0.1640
|
32
|
36
|
|
3/16 [#10]
|
0.1900
|
24
|
32
|
|
1/4
|
0.2500
|
20
|
28
|
|
5/16
|
0.3125
|
18
|
24
|
|
3/8
|
0.3750
|
16
|
24
|
|
7/16
|
0.4375
|
14
|
20
|
|
1/2
|
0.5000
|
13
|
20
|
|
9/16
|
0.5625
|
12
|
18
|
|
5/8
|
0.6250
|
11
|
18
|
|
3/4
|
0.7500
|
10
|
16
|
|
7/8
|
0.8750
|
9
|
14
|
|
1
|
1.0000
|
8
|
12, 14
|
|
1 1/8
|
1.1250
|
7
|
12
|
|
1 1/4
|
1.2500
|
7
|
12
|
|
1 3/8
|
1.3750
|
6
|
12
|
|
1 1/2
|
1.5000
|
6
|
12
|
|
1 3/4
|
1.7500
|
5
|
–
|
Duplex S31803 Type Stud Bolt
Stainless Steel Stud Bolt Surface Coating :
- Hot Dipped Galvanizing
- Epoxy Coating
- Electro Polished
- Passivation
- Zinc Plating
- Chrome Plating
- Mirror Buffed
- Teflon Coating
- Oxidized
Duplex S31803 Price Per Kg (As per demand and manufacturer):
| Price of Duplex S31803 Stud Bolt manufacturer in India | Price in USD (per kg) | Price in Euro (per kg) | Price in UAE Dirham (per kg) |
|---|---|---|---|
| Duplex Stainless Steel Stud Bolt Grade – S31803 | $6.82 | €6.52 | 22.84 UAE Dirham |
| Duplex Stainless Steel Double End Stud Bolt S31803 | $5.92 | €5.67 | 19.55 UAE Dirham |
| Duplex Stainless Steel Square Nuts Grade – S31803 | $3.92 | €3.74 | 12.23 UAE Dirham |
