Alloy Steel Sheets & Plates

Table of Content

  •   What is Alloy Steel Sheets & Plates
  •   Specification of Alloy Steel Sheets & Plates
  •   Comparable Alloy Steel Plate Specifications, Pipe Specifications and Forging Specifications
  •   Chemical Composition of Alloy Steel Sheets & Plates
  •   Mechanical Properties of Alloy Steel Sheets & Plates
  •   Dimensions of Alloy Steel Sheets & Plates
  •   Thickness Chart of Alloy Steel Sheets & Plates
  •   Weight Chart of Alloy Steel Sheets & Plates
  •   Alloy Steel Type Sheets & Plates
  •   Alloy Steel Price Per Kg (As per demand and manufacturer)
  •   People also Search for Alloy Steel Sheets & Plates
  •   Export Destinations
  •   Domestic Supply

    • Titanium Alloy Steel Gr 1 industrial Sheets & Plates, Werkstoff Nr. 1.4301 high tensile Sheets & Plates, X5Crni18-10 industrial Sheets & Plates, ASME SA193 Hot Forged Sheets & Plates, ASTM A193 industrial Sheets & Plates.

    An ISO 9001:2008 Certified Company, Ranflex Metals is a full line distributor, processor and supplier of alloy steel plates in one of the most popular pressure vessel grade ASME SA387 or ASTM A387. We can supply cut to size Chrome Moly steel plates, with both narrow and wide widths. Our stock of alloy steel plates includes thickness of 3mm up to 100mm with width of 1500mm, 2000mm, and 2500mm.

    Alloy Steel Sheets & Plates

    TitaniumAlloy SteelGr 1 industrial Sheets & Plates trader, ASTM A193 industrial Sheets & Plates supplier, JIS SUS Gr 1 high tensile Sheets & Plates distributor, high tensile Sheets & Plates retailer, TitaniumAlloy Steel2332 industrial Sheets & Plates exporter, ASTM A193 industrial Sheets & Plates dealer, JIS SUS Gr 1 high tensile Sheets & Plates price list in India.

    An ISO 9001:2008 Certified Company, Ranflex Metals is an international distributor and supplier of Cr Mo Alloy Steel Plates (ASTM A 387 Grade 11/22 Class 2). Ranflex Metals stocks an extensive range of high quality alloy steel plates for manufacturing pressure vessels and industrial boilers for the petroleum, petrochemical and chemical processing industries. Two of the most popular pressure vessel steel grades include ASME SA 516 (ASTM A516) carbon steel and ASME SA 387 (ASTM A387) alloy steel. Thicknesses available in range from 3 mm up to as thick as 100 mm, although thicker plates might be manufactured under special order.

    ASTM A387 / A387M – Specification for Pressure Vessel Plates, Alloy Steel, Chromium-Molybdenum
    This specification covers chromium-molybdenum alloy steel plates for welded boilers and pressure vessels designed for elevated temperature service. Materials considered under this specification are available in grades 2, 12, 11, 22, 22L, 21, 21L, 5, 9 and 91. The steel materials shall be killed and shall be thermally treated. The steel specimens shall undergo heat analysis and product analysis and shall conform to the chemical requirements for carbon, manganese, phosphorus, sulfur, silicon, chromium, molybdenum, nickel, vanadium, columbium, boron, nitrogen, aluminum, titanium, and zirconium. The steel specimens shall also undergo tension tests and shall conform to the required values of tensile strength, yield strength, and elongation.

    EN 58E industrial Sheets & Plates, ASTM A193 Hot Forged Sheets & Plates, JIS SUS Gr 1 industrial Sheets & Plates, BS Gr 1S31 Hot Forged Sheets & Plates, X5Crni18-10 high tensile Sheets & Plates, EN 58E high tensile Sheets & Plates.

    Specification of Alloy Steel Sheets & Plates :

    Specifications: ASTM A387 / ASME SA387
    Thickness: 4 mm To 100 mm
    Length: 2000mm, 2438mm, 3000mm, 5800mm, 6000mm,12000mm，or as required
    Width: 40mm-600mm, 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm,or as required
    Application Building industry,architectural decoration,elevators,building doors,panels and so on.
    Standard: ASTM，AISI，JIS，GB， DIN，EN
    Surface: BA，2B，NO.1，NO.4，4K，HL，8K
    Certification: ISO, SGS，BV
    Technique: Cold Rolled Hot Rolled
    Finish Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
    Form Sheets, Plates, Coils, Slatting Coils, Perforated Coils

    Comparable Alloy Steel Plate, Pipe, and Forging :

    Plate Grade Forging/Flange Grade A182 Pipes Grade ASTM A335
    BSEN10028-2 16M03 F1 P1
    ASTM A387-12-2 F12-2 P12
    ASTM A387-11-2 F11-2 P11
    ASTM A387-22-2 F22 P22
    ASTM A387-5-2 F5 P5
    ASTM A387-91-2 F9 P91

    Chemical Composition of Alloy Steel Sheets & Plates :

    C Mn P S SI Cr Mo
    Grade 5 0.15 max 0.3 – 0.6 0.035 0.03 0.5 max 4.00 – 6.00 0.45 – 0.65
    Grade 9 0.15 max 0.30 – 0.6 0.03 0.03 1.0 max 8.0 – 10.0 0.9 – 1.1
    Grade 11 0.05 – 0.17 0.4 – 0.65 0.035 0.035 0.5 – 0.80 1.0 – 1.5 0.45 – 0.65
    Grade 12 0.05 – 0.17 0.4 – 0.65 0.035 0.035 0.15 – 0.4 0.8 – 1.15 0.45 – 0.6
    Grade 22 0.05 – 0.15 0.3 – 0.6 0.035 0.035 0.5 max 2.0 – 2.5 0.9 – 1.1

    Mechanical Properties of Alloy Steel Sheets & Plates :

      Tensile Strength



    (ksi)

    		 Tensile Strength



    (MPa)

    		 Yield Strength



    (ksi)

    		 Yield Strength (MPa) Elongation



    in 2 inches (%)
    A 387 Grade 5 Class 1 60-85 415-585 30 205 18
    Class 2 75-100 515-690 45 310 18
    A 387 Grade 9 Class 1 60-85 415-585 30 205 18
    Class 2 75-100 515-690 45 310 18
    A 387 Grade 11 Class 1 60-85 415-585 35 240 22
    Class 2 70-90 485-620 45 310 22
    A 387 Grade 12 Class 1 50-80 380-550 33 230 22
    Class 2 65-85 450-585 40 275 22
    A 387 Grade 22 Class 1 60-85 415-585 30 205 18
    Class 2 75-100 515-690 45 310 18

    JIS SUS Gr 1 industrial Sheets & Plates retailer, TitaniumAlloy Steel2332 high tensile Sheets & Plates stockyards, TitaniumAlloy SteelGr 1 industrial Sheets & Plates At Factory Price, X5Crni18-10 high tensile Sheets & Plates dealer, JIS SUS Gr 1 Hot Forged Sheets & Plates catalogue, Hot Forged Sheets & Plates stockist, EN 58E high tensile Sheets & Plates At Factory Price.

    Modern Equipments

    Expert Engineers

    Efficient Factories

    Well Maintained

    Dimensions of Alloy Steel Sheets & Plates :

    Alloy Steel Sheets & Plates dimensions

    Sheet & Plate Surface finish Thickness (mm) Width (max mm)
    2B – Cold rolled, heat treated, pickled, skin passed Sheet 0.25–8.0 2032
    2D – Cold rolled, heat treated, pickled Sheet 0.4–6.35 1524
    2E – Cold rolled, heat treated, mechanically descaled plate 0.4–8.0 2032
    2R – Cold rolled, bright annealed plate 0.25–3.5 1524
    2H – Work hardened plate 0.4–6.35 1524
    Polished, brushed plate 0.5–4.0 1524
    ASTM A240Alloy SteelSheet & Plate Imperial Dimensions :
    Sheet & Plate Surface finish Gauge (in) Width (max in)
    2B – Cold rolled, heat treated, pickled, skin passed Plate 10–24 72*
    2D – Cold rolled, heat treated, pickled plate 12–24 60
    BA Mexinox only 18–28 48
    Polished Sheet (not brushed) 11–24 60
    Temper rolled Sheet Mexinox only 13–29 48

    Thickness Chart of Alloy Steel Sheets & Plates :

    Thickness Thickness Size Range Surface Area per Unit weight Approx Weight per Sheet
    inches mm   lbs/ft² kg/m² lbs kg
    0.015 0.381 36 x 96 0.630 3.07566 15.12 6.84936
    0.015 0.381 36 x 120 0.630 3.07566 18.90 8.5617
    0.0178 0.45212 36 x 96 0.756 3.690792 18.15 8.22195
    0.0178 0.45212 36 x 120 0.756 3.690792 22.68 10.27404
    0.0178 0.45212 48 x 96 0.756 3.690792 24.19 10.95807
    0.0178 0.45212 48 x 120 0.756 3.690792 30.24 13.69872
    0.0235 0.5969 30 x 96 1.008 4.921056 20.16 9.13248
    0.0235 0.5969 30 x 120 1.008 4.921056 25.20 11.4156
    0.0235 0.5969 36 x 96 1.008 4.921056 24.19 10.95807
    0.0235 0.5969 36 x 120 1.008 4.921056 30.24 13.69872
    0.0235 0.5969 36 x 144 1.008 4.921056 36.29 16.43937
    0.0235 0.5969 48 x 96 1.008 4.921056 32.26 14.61378
    0.0235 0.5969 48 x 120 1.008 4.921056 40.32 18.26496
    0.0235 0.5969 48 x 144 1.008 4.921056 48.39 21.92067
    0.0291 0.73914 30 x 96 1.260 6.15132 25.20 11.4156
    0.0291 0.73914 30 x 120 1.260 6.15132 31.50 14.2695
    0.0291 0.73914 36 x 96 1.260 6.15132 30.24 13.69872
    0.0291 0.73914 36 x 120 1.260 6.15132 37.80 17.1234
    0.0291 0.73914 36 x 144 1.260 6.15132 45.37 20.55261
    0.0291 0.73914 48 x 96 1.260 6.15132 40.32 18.26496
    0.0291 0.73914 48 x 120 1.260 6.15132 50.41 22.83573
    0.0291 0.73914 48 x 144 1.260 6.15132 60.49 27.40197
    0.0355 0.9017 30 x 96 1.512 7.381584 30.24 13.69872
    0.0355 0.9017 30 x 120 1.512 7.381584 37.80 17.1234
    0.0355 0.9017 36 x 96 1.512 7.381584 36.29 16.43937

    Weight Chart of Alloy Steel Sheets & Plates :

    Plate Thickness (mm) Weight (kg/m) kg/meter (width 1200mm) kg/meter (width 1500mm) kg/meter (width 1800mm) kg/meter (width 2400mm)
    3 23.55 28.3 35.3 42.4 56.5
    4 31.4 37.7 47.1 56.5 75.4
    5 39.25 47.1 58.9 70.7 94.2
    6 47.1 56.5 70.7 84.8 113
    8 62.8 75.4 94.2 113 150.7
    10 78.5 94 118 141 188
    12 94.2 113 141 170 226
    16 125.6 151 188 226 301
    20 157 188 236 283 377
    22 172.7 207 259 311 415
    25 196.25 236 294 353 471
    28 219.8 264 330 396 528
    32 251.2 301 377 452 603
    36 282.6 339 424 509 678
    40 314 377 471 565 754
    45 353.25 424 530 636 848
    50 392.5 471 589 707 942
    55 431.75 518 648 777 1036
    60 471 565 707 848 1130
    65 510 612 765 918 1224
    70 549.5 659 824 989 1319
    75 588.75 707 883 1060 1413
    80 628 754 942 1130 1507
    90 706.5 848 1060 1272 1696
    100 785 942 1178 1413 1884

    Weight Per Square Meter of Alloy Steel Sheets & Plates :
    Size (mm) Weight per
    Sheet (Kg)    		 Size (mm) Weight per
    Sheet (Kg)
    2000 x1000 x 0.7 11.5 2500 x 1250 x 1.5 38.4
    2500 x1250 x 0.7 17.9 3000 x 1500 x 1.5 55.3
    2000 x1000 x 0.9 14.7 2000 x 1000 x 2.0 32.7
    2500 x1250 x 0.9 23.0 2500 x 1250 x 2.0 51.2
    2000 x1000 x 1.0 16.4 3000 x 1500 x 2.0 73.7
    2500 x1250 x 1.0 25.6 2000 x 1000 x 2.5 40.9
    3000 x1500 x 1.0 36.8 2500 x 1250 x 2.5 63.9
    2000 x1000 x 1.2 19.6 3000 x 1500 x 2.5 92.1
    2500 x1250 x 1.2 30.7 2000 x 1000 x 3.0 49.6
    3000 x1500 x 1.2 44.2 2500 x 1250 x 3.0 77.5
    2000 x1000 x 1.5 24.6 3000 x 1500 x 3.0 112.0

    Weight – Imperial Units of Alloy Steel Sheets & Plates :
    Nominal Size Thickness
    (inches)    		 Weight
    (lb/ft2)
    3/16 7.65
    1/4 10.2
    5/16 12.8
    3/8 15.3
    7/16 17.9
    1/2 20.4
    9/16 22.9
    5/8 25.5
    11/16 28.1
    3/4 30.6
    13/16 33.2
    7/8 35.7
    1 40.8
    1 1/8 45.9
    1 1/4 51.0
    1 3/8 56.1
    1 1/2 61.2
    1 5/8 66.3
    1 3/4 71.4
    1 7/8 76.5
    2 81.6
    2 1/8 86.7
    2 1/4 91.8
    2 1/2 102
    2 3/4 112
    3 122
    3 1/4 133
    3 1/2 143
    3 3/4 153
    4 163
    4 1/4 173
    4 1/2 184
    5 204
    5 1/2 224
    6 245
    6 1/2 265
    7 286
    7 1/2 306
    8 326
    9 367
    10 408

    Weight – Metric Units of Alloy Steel Sheets & Plates :
    Plate Thickness
    (mm)    		 Weight
    (kg/m2)
    1.6 12.6
    2.0 15.7
    2.5 19.6
    3 23.6
    3.2 25.1
    4 31.4
    5 39.3
    6 47.1
    8 62.8
    10 78.5
    12.5 98.1
    15 118
    20 157
    22.5 177
    25 196
    30 236
    32 251
    35 275
    40 314
    45 353
    50 393
    55 432
    60 471
    65 510
    70 550
    75 589
    80 628
    90 707
    100 785
    110 864
    120 942
    130 1051
    150 1178
    160 1256
    180 1413
    200 1570
    250 1963

    Alloy SteelType Sheets & Plates

    Alloy Steel Sheets

    Alloy Steel Sheet
    Alloy SteelPlates

    Alloy Steel Plate
    Alloy SteelChequered Plate

    Alloy Steel Chequered Plate


    Alloy SteelShim Sheet

    Alloy Steel Shim Sheet
    Alloy SteelPerforated Sheet

    Alloy Steel Perforated Sheet
    Alloy SteelClad Plate

    Alloy Steel Clad Plate


    Alloy SteelPrice Per Kg (As per demand and manufacturer):

    Price of Alloy Steel Sheets & Plates manufacturer in India Price in USD (per kg) Price in Euro (per kg) Price in UAE Dirham (per kg)
    Alloy Steel Sheet 280 - 300 3.25 - 3.49 13.51 - 14.47
    Alloy Steel Plate 300 - 350 3.49 - 4.07 14.47 - 16.88
    Alloy Steel Sheet manufacturer 290 - 310 3.35 - 3.59 13.61 - 14.57
    Alloy Steel Plate manufacturer 310 - 360 3.59 - 4.17 14.57 - 16.98
